HTTP Request Node

The HTTP Request node lets you connect to any website or online service. Use it when you need to get data from a website, send data somewhere, or connect to services that aren’t in the built-in app list. Think of it like opening a browser and going to a web address, but automated.

When to Use

Services not in the app list - Connect to any website or service
Your company’s systems - Connect to internal tools and databases
Advanced connections - When you need precise control over how you connect
Sending data - Push information to other systems

If you’re connecting to Gmail, Slack, Google Sheets, or other popular apps, use App Action instead - it’s much easier to set up.

Example: REST API Integration

Query a customer API and process the results:

Configure the request

Add an HTTP Request node:

Method: GET
URL: https://api.example.com/customers/{{webhook_1.body.customerId}}
Headers:

{
  "Authorization": "Bearer {{secrets.API_KEY}}",
  "Accept": "application/json"
}

Handle the response

Add a Condition node to check success:

{{http_request_1.statusCode}} == 200

Use the data

Access response data in subsequent nodes:

Customer name: {{http_request_1.body.name}}
Email: {{http_request_1.body.email}}
Account tier: {{http_request_1.body.subscription.tier}}

Example: POST with JSON Body

Create a record in an external system: Configuration:

Method: POST
URL: https://api.example.com/leads
Body type: json
Body:

{
  "name": "{{webhook_1.body.name}}",
  "email": "{{webhook_1.body.email}}",
  "source": "cogniagent_workflow",
  "metadata": {
    "campaign": "{{webhook_1.body.campaign}}",
    "timestamp": "{{timestamp}}"
  }
}

Example: GraphQL Query

Query a GraphQL API: Configuration:

Method: POST
URL: https://api.example.com/graphql
Headers:

{
  "Content-Type": "application/json",
  "Authorization": "Bearer {{secrets.GRAPHQL_TOKEN}}"
}

Body:

{
  "query": "query GetUser($id: ID!) { user(id: $id) { name email orders { id total } } }",
  "variables": {
    "id": "{{webhook_1.body.userId}}"
  }
}

Accessing the response:

Name: {{http_request_1.body.data.user.name}}
Order count: {{http_request_1.body.data.user.orders.length}}

Example: File Upload

Upload a file using form data: Configuration:

Method: POST
URL: https://api.example.com/upload
Body type: form
Body:

{
  "file": "{{parse_file_1.fileContent}}",
  "filename": "report.pdf",
  "description": "Generated report"
}

Logging In (Authentication)

Different services require different ways to prove you’re allowed to connect.

Using a Token (Most Common)

Many modern services give you a token - a long string of characters - to prove who you are:

{
  "type": "bearer",
  "token": "{{secrets.API_TOKEN}}"
}

Using Username and Password

Some older services use traditional login:

{
  "type": "basic",
  "username": "{{secrets.API_USER}}",
  "password": "{{secrets.API_PASS}}"
}

Using an API Key

Some services give you a special key instead of a token:

{
  "type": "apiKey",
  "key": "X-API-Key",
  "value": "{{secrets.API_KEY}}",
  "in": "header"
}

Error Handling

Always check the response status:

├── HTTP Request
├── Switch (based on statusCode)
│   ├── 200-299: Continue normal flow
│   ├── 400: Set Variable (bad request error)
│   ├── 401: External API (refresh token) → Retry
│   ├── 429: Sleep (30s) → Retry
│   └── 500+: External API (alert team)

Simple success check:

├── HTTP Request
├── Condition (success == true)
│   ├── Met: Continue
│   └── Unmet: Handle error

Response Parsing

JSON (automatic)

If the response has Content-Type: application/json, it’s automatically parsed:

{{http_request_1.body.data.items[0].name}}

Raw Text

For non-JSON responses, body is a string:

{{http_request_1.body}}

Parse it in an Execute Code node if needed.

Binary/Files

For binary responses, the body contains base64-encoded data. Use Execute Code to process.

Retry Configuration

Configure retries for transient failures:

{
  "maxRetries": 3,
  "retryDelay": 1000,
  "retryOn": [429, 500, 502, 503, 504]
}

Retries use exponential backoff by default: 1s, 2s, 4s…

Best Practices

Use Variables for URLs

# Good - configurable
https://{{env.API_HOST}}/api/v2/customers

# Avoid - hardcoded
https://api.production.example.com/api/v2/customers

Store Secrets Securely

Never hardcode API keys in the URL or body. Use workspace secrets:

Authorization: Bearer {{secrets.MY_API_KEY}}

Handle Rate Limits

Check for 429 status and implement backoff:

├── HTTP Request
├── Condition (statusCode == 429)
│   ├── Met: Sleep ({{http_request_1.headers.retry-after * 1000}}) → Loop back
│   └── Unmet: Continue

Validate Responses

Don’t assume success. Check status codes and validate expected fields:

# In Execute Code node
response = input["http_request_1"]

if not response["success"]:
    return {"error": f"API returned {response['statusCode']}"}

if "data" not in response["body"]:
    return {"error": "Missing data field in response"}

return {"success": True, "data": response["body"]["data"]}

Tips

Use the built-in request tester to debug API calls before adding them to your workflow. Click “Test Request” in the configuration panel.

For APIs with complex authentication (OAuth 2.0 flows), consider using External API if the service is supported, or handle token refresh in a separate workflow.

Be careful with sensitive data in URLs - query parameters may be logged. Use headers or request body for sensitive values.

Settings

name

string

default:"HTTP Request"

What to call this node (shown on the canvas).

key

string

default:"http_request_1"

A short code to reference this node’s response.

method

string

required

What type of request to make:

GET - Retrieve data (like loading a webpage)
POST - Send data (like submitting a form)
PUT/PATCH - Update existing data
DELETE - Remove data

url

string

required

The web address to connect to. You can include data from previous nodes.

headers

object

Extra information to send with the request (often needed for login credentials).

queryParams

object

Values to add to the web address (like ?search=hello).

body

any

The data to send (when using POST, PUT, or PATCH).

bodyType

string

default:"json"

What format the data is in: json (most common), form, raw, or none.

authentication

object

How to log in:

none - No login needed
bearer - Use a token (common for modern services)
basic - Use a username and password
apiKey - Use a special key

timeout

number

default:"30000"

How long to wait (in milliseconds) before giving up. 30000 = 30 seconds.

followRedirects

boolean

default:"true"

Whether to automatically follow if the site redirects you somewhere else.

maxRetries

number

default:"3"

How many times to try again if it fails.

Outputs

body

any

The data that came back (the main response).

statusCode

number

A number showing if it worked:

200 = Success
404 = Not found
500 = Something went wrong on their end

headers

object

Extra information that came with the response.

success

boolean

True if it worked, false if not.

responseTime

number

How long it took (in milliseconds).

App Action

Simpler interface for 600+ integrated apps.

Execute Code

For complex request/response processing.
